SIS
Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-34
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Information requests (continued)
Query part number N N
60-742-xx
]
See appendix B for part numbers.
View internal temperature 20S 20S
X4&]
Display temperature in degrees Fahrenheit.
File directory
N
The response to the ViewFile Directory command differs, depending on whether the command is sent via an RS-232/RS-422 or a Telnet connection or is sent via a Web browser
connection.
View file directory
RS-232/RS-422 port and Telnet
E
DF
}
filename1,date/time,length
]
filename2,date/time,length
]
filename3,date/time,length
]
•
•
•
•
filenamen,date/time,length
]
# of Bytes•Left
]]
List user-supplied les.
View file directory
Web browser
E
DF
}
Var file = new array (); List user-supplied les.
File [1] = ‘filename1,date1,filesize1‘;
File [2] = ‘filename2,date2,filesize2‘;
•
•
•
•
File [n] = ‘filenamen,daten,filesizen‘;
File [n+1] = # of Bytes•Left
Erase user-supplied Web pages/
files
E
filenameEF
}
Delfilename
]
Resets
Reset all audio adjustments
E
ZA
}
WZA
|
Zpa
]
Reset all ISS settings to factory
defaults
E
ZXXX
}
WZXXX
|
Zpx
]
N
The reset all command (
E
ZXXX
}
) can take a few seconds.
Absolute reset
E
ZQQQ
}
WZQQQ
|
Zpq
]
Same as reset all (
E
ZXXX
}
), plus reset the
IP address to 192.168.254.254 and delete user
and administrator passwords.
Command/response table for SIS commands (continued)
N
X4&
= Degrees Celsius 1 – 6
X4%
= Lockout mode 0 = unlocked 1 = Program lock 2 = Switch free lock 3 = Volume free lock 4 = Complete lock
