ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Vertical position
Specify a vertical position
7*
X1&
/ 7*
X1&
/ 7Vph
X1&]
Specify the vertical position of the scan
converted output.
Increment up 7+/ 7*/
7Vph
X1&]
Move the scan converted output up one pixel.
Increment down 7-/ 7-/
7Vph
X1&]
Move the scan converted output down one pixel.
View the vertical position 7/ 7/
X1&]
Show the vertical position of the first line.
Horizontal size
Set a specific horizontal size
7*
X1^
: 7*
X1^
:
7Hsz
X1^]
Set the scan converted output’s horizontal size
to
X1^
.
Increment horizontal size
7+
: 7+:
7Hsz
X1^]
Make the scan converted output one pixel wider.
Decrement horizontal size
7-
: 7-:
7Hsz
X1^]
Make the scan converted output one pixel
narrower.
View the horizontal size value
7
: 7:
X1^]
Show the horizontal size of the scan converted
output.
Vertical size
Set a specific vertical size
7*
X1^
; 7*
X1^
;
7Vsz
X1^]
Set the scan converted output’s vertical size to
X1^
.
Increment vertical size
7+
; 7+;
7Vsz
X1^]
Make the scan converted output one pixel taller.
Decrement vertical size
7-
; 7-;
7Vsz
X1^]
Make the scan converted output one pixel
shorter.
View the vertical size value
7
; 7;
X1^]
Show the vertical size of the scan converted
output.
Scan converter horizontal filter
N
The command (D) is case sensitive.
Set detail level
7*
X4!
D 7*
X4!
D 7Dhz
X4!]
Specify the horizontal detail level.
Increment detail level 7*+D 7*+D
7Dhz
X4!]
Increase horizontal detail level by one step.
Decrement detail level 7*-D 7*-D
7Dhz
X4!]
Decrease horizontal detail level by one step.
View detail level 7D 7D
X4!]
Show the horizontal detail level.
Command/response table for SIS commands (continued)
N
X1^
= Size Up to 4095
X1&
= Position value Up to 4095
X4!
= Scan converter horzontal filter / flicker filter value 0 – 3
