HTML Operation, cont’d
ISS 506 Integration Seamless Switcher • HTML Operation
6-14
Preset page
You can save and recall user presets and input presets from the Presets page
(figure 6-13). Access the Presets page by clicking the Presets link on the User
Control page.
Refresh
User Control
PIP setup
Logos
Figure 6-13 — Presets page
User presets
N
User presets consist of:
• Filmmode • Totalpixels
Programphase • Previewphase
Horizontalstart • Verticalstart
Horizontalactivepixels • Verticalactivepixels
Horizontalsize • Verticalsize
Brightnesssandcontrast • Detail
• Horizontalposition • Verticalposition
• Color • Tint
There are three user presets for each output (preview and program). The user
presets define a set of picture adjustment settings, listed above, for the associated
output. Save or recall a user preset as follows:
1
. Click the Program or Preview preset number
dropbox.
2. Select the desired preset number.
3. Click either the Save or Recall button.
