ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Title
Eff3*
X^
*nnn*1*
X&
]
The operator has pressed the Effect Title button on the front panel. Eff3 indicates
“title”.
X^
is the key threshold. “nnn” has no meaning in this response. The “1”
after nnn indicates that this effect is selected.
X&
is the title status (displayed or not
displayed).
PIP
Eff4*
X#
*
X%
*1*
X&
]
The operator has pressed the Effect PIP button on the front panel. Eff4 indicates
“PIP”.
X%
is the PIP switching subeffect. The “1” after
X%
indicates that this effect
is selected.
X#
is the PIP switching duration.
X&
is the PIP status (PIP displayed or
not displayed).
Take and busy
Tke1*
X*
]
Bsy
n
]
A switching operation involving an effect (wipe, dissolve, PIP, or title) has been
initiated (Tke) and the switcher is reporting the effect’s status (Bsy
n
). The switcher
issues a series of messages, the number and sequence of which depend on the effect
type and, for wipes or dissolves, the switch mode (swap or stay). See “Preview
Switch Mode submenu” in chapter 3, “Installation”, for more information on swap
and stay mode.
Wiping or dissolving in stay mode
The switcher issues the following messages when you switch the input that is
applied to the preview output to the program output in stay mode with a wipe or
dissolve effect:
N
The sequence of commands may vary, but you should see all of the listed
commands.
Tke1*
X*
] The switcher has received the front panel
Take command.
Bsy1]
The switcher is performing the selected
effect (wipe or dissolve).
Reconfig1]
The input to the program output has
Reconfig2] changed (to the input that had been
switched to preview output).
Bsy0]
The switcher is finished performing the
selected effect (wipe or dissolve).
