4-35
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Command/Response Table for IP SIS Commands
Symbol definitions
X7)
= Switcher name (Up to 240 alphanumeric characters)
N
The following characters are invalid in the name: {space} ~ , _ @ = ` [ ] { } < > ‘ “ ; : | \ and ?.
X7!
= Default name ISS-506-Series- + last 3 pairs of the MAC address
X7@
= Timeanddate(forset) Intheformat:MM/DD/YY•HH:MM:SS where:
MM = month: 01 (January) through 12 (December)
DD = 01 through 31
YY = 00 through 99
HH=00through24
MM = 00 through 59
SS = 00 through 59
X7#
= Timeanddate(forread) Intheformat:Day,•DD•Mmm•YYYY•HH:MM:SS where:
Day = weekday: Mon through Sun
DD = 01 through 31
Mmm = month: Jan through Dec
YYYY = 2000 through 2099
HH=00through24
MM = 00 through 59
SS = 00 through 59
X7$
= GMToffset –12.0through+14.0.HoursandminutesremovedfromGMT
X7%
= DaylightSavingsTime 0=DaylightSavingsTimeoff/ignore
1=DaylightSavingsTimeon(northernhemisphere)
2=DaylightSavingsTimeon(Europe)
3=DaylightSavingsTimeon(Brazil)
X7^
= IP address ###.###.###.###
X7&
= Hardware(MAC)address ##-##-##-##-##-##
X7*
= Number of open connections 0 - 255
X7(
= Password 12 alphanumeric characters
N
The following characters are invalid in passwords: {space} + ~ , @ = ` [ ] { } < > ‘ “ ; : | \ and ?.
X8)
= Domain name Standard domain name rules apply (for example: nnnnn@xxx.com)
N
The following characters are invalid in a domain name: {space} + ~ , = ` [ ] { } < > ‘ “ ; : | \ and ?. The @ character is only acceptable as
the lead-in to the domain name (such as @extron.com).
X8!
= E-mailaccount 65-72.65=e-mailrecipient1,66=2,67=3,...72=recipient#8
X8@
= E-mailaddress Typicale-mailaddressformat(forexample:nnnn@xxx.com)
X8#
= Notify when? 0 = no response 2 = fixed/restored
1 = fail/missing 3 = both 1 & 2
X8$
= Notification selections 01 through 12 = input 1 through input 12
13 through 16 = not used
17=powersupply
X8%
= Notifystatus(forread) 17-digitnumber.Foreachdigit:0=donotnotify,1=notify
X8^
= DHCP 0=off,1=on
X8&
= Port # 00 through 99 (00 = all ports)
X8*
= Baudrate 9600,19200,38400,115200
X8(
= Parity odd, even,none, mark, space (only first letter required)
X9)
= Databits 7,8
X9!
= Stop bits 1, 2
X9@
= Port type 0 = RS-232 1 = RS-422
X9#
= Verbose mode 0 = clear/none (default for Telnet connection)
1=verbosemode(defaultforRS-232/RS-422connection)
2 = tagged responses for queries
3=verbosemodeandtaggedforqueries
N
If tagged responses is enabled, all read commands return the constant string and the value as the set command does
(for example, the read matrix name command
E
CN
}
, returns Ipn•
X7)]
).
X9$
= RAMstatus 0=RAMdirty(needssavingtoash)
1=RAMhasbeensaved(oktopoweroff/reset)
