Operation, cont’d
ISS 506 Integration Seamless Switcher • Operation
3-12
Resolution and refresh rate submenu
Rotate the Adjust [ knob while this submenu is active to select one of the available
output resolutions. See the table below.
Rotate the Adjust { knob while this submenu is active to select one of the available
refresh (vertical scanning) rates. See the table below.
Frequency (Hz)
Resolution 24 25 30 50 59.94 60 72 96 100 120
640 x 480 • • • • • •
800 x 600 • • • • • •
852 x 480 • • • • •
1024 x 768 • • • •
1024 x 852 • • • •
1024 x 1024 • • •
1280 x 768 • • • •
1280 x 1024 • • •
1360 x 765 • • •
1365 x 768 • • •
1366 x 768 • • •
1365 x 1024 • •
1400 x 1050 • •
1600 x 1200 • •
480p • •
576p • •
720p • • • • •
1080i • • •
1080p • • • • • •
1864 x 1050 • •
1280 x 800 • • •
1440 x 900 • • •
1680 x 1050 • •
1080p Sharp •
1920 x 1200* •
* 1920 x 1200 is available only in units that shipped after the first quarter of 2009.
The default resolution and rate is 1024 x 768 @ 60 Hz.
N
1080p Sharp is an HDTV 1080p rate specifically tailored to Sharp
®
Professional
displays (such as the G655u).
Changing the output resolution sets any assigned logos to black.
User presets are associated with an output resolution. Once you change the
output resolution, the previously saved presets have no effect.
