4-27
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Horizontal shift logo
Set a specific horizontal position
5*
X3%
*
X1&
H 5*
X3%
*
X1&
H 5Hph
X3%
*
X1&]
Specify the horizontal position of logo
X3%
.
Increment right
5*
X3%
+H 5*
X3%
+H 5Hph
X3%
*
X1&]
Shift logo
X3%
one pixel to the right.
Decrement left
5*
X3%
-H 5*
X3%
-H 5Hph
X3%
*
X1&]
Shift logo
X3%
one pixel to the left.
View horizontal position
5*
X3%
H 5*
X3%
H
X1&]
View logo
X3%
’s horizontal setting.
Vertical shift logo
Set a specific vertical position
5*
X3%
*
X1&
/ 5*
X3%
*
X1&
/ 5Vph
X3%
*
X1&]
Specify the vertical position of logo
X3%
.
Increment
5*
X3%
+/ 5*
X3%
+/ 5Vph
X3%
*
X1&]
Shift logo
X3%
down one line.
Decrement
5*
X3%
-/ 5*
X3%
-/ 5Vph
X3%
*
X1&]
Shift logo
X3%
up one line.
View vertical position
5*
X3%
/ 5*
X3%
/
X1&]
View logo
X3%
’s vertical setting.
Logo size
View horizontal size
5*
X3%
: 5*
X3%
: 5Hsz
X1^]
View the horizontal width of logo
X3%
.
View vertical size
5*;
X3%
5*
X3%
; 5Hsz
X1^]
View the vertical height of logo
X3%
.
Picture-in-Picture
PIP detail filter
N
The command (D or d) is not case sensitive except when used in conjunction with the optional scan converter output board. See the Optional Scan converter board commands,
on page 4-30.
Set detail level
4*
X2&
D 4*
X2&
D 4Det
X2&]
Specify the detail level.
Increment detail level 4*+D 4*+D
4Det
X2&]
Increase the detail level by one step.
Decrement detail level 4*-D 4*-D
4Det
X2&]
Decrease the detail level by one step.
View detail level 4D 4D
X2&]
Show the detail level.
PIP window horizontal shift
Set a specific horizontal position
3*
X1&
H 3*
X1&
H 3Hph
X1&]
Specify the horizontal position of the PIP
window.
Increment right 3+H 3+H
3Hph
X1&]
Shift the PIP window one pixel to the right.
Decrement left 3-H 3-H
3Hph
X1&]
Shift the PIP window one pixel to the left.
View horizontal position 3H 3H
X1&]
View the PIP window’s position setting.
Command/response table for SIS commands (continued)
N
X1^
= Size Up to 4095
X1&
= Position value Up to 4095
X2&
= Picture adjustments 000 – 127
(color, tint, brightness, detail)
X3%
= Logo name 1 or 2
