4-19
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Pixel phase
N
The pixel phase adjustment is available only for RGB, YUV-HD, and YUVp inputs.
Set a specific pixel sampling phase
X@
*
X!
*
X2)
U
X@
*
X!
*
X2)
U
X@
Phs
X!
*
X2)]
Specify the pixel sampling phase.
Increment sampling value
X@
*
X!
+U
X@
*
X!
+U
X@
Phs
X!
*
X2)]
Increase the phase value.
Decrement sampling value
X@
*
X!
-U
X@
*
X!
-U
X@
Phs
X!
*
X2)]
Decrease the phase value.
View the sampling value
X@
*
X!
U
X@
*
X!
U
X2)]
Show the pixel sampling phase.
Total pixels
N
The pixel phase adjustment is available only for RGB, YUV-HD, and YUVp inputs.
Set a specific total pixels value
11*
X!
*
X2!
#
X!
*
X2!
# Tpx
X!
*
X2!]
Specify the number of total pixels.
Increment total pixels value
11*
X!
+# 11*
X!
+# Tpx
X!
*
X2!]
Increase the total number of pixels value.
Decrement total pixels value
11*
X!
-# 11*
X!
-# Tpx
X!
*
X2!]
Decrease the total number of pixels value.
View the total pixels value
11*
X!
# 11*
X!
#
X2!]
Show the total number of pixels.
Active pixels
Set a specific active pixels value
12*
X!
*
X2@
# 12*
X!
*
X2@
# Apx
X!
*
X2@]
Specify the number of active pixels.
Increment active pixels value
12*
X!
+# 12*
X!
+# Apx
X!
*
X2@]
Increase the number of active pixels value.
Decrement active pixels value
12*
X!
-# 12*
X!
-# Apx
X!
*
X2@]
Decrease the number of active pixels value.
View the active pixels value
12*
X!
# 12*
X!
#
X2@]
Show the number of active pixels.
Active lines
Set a specific active lines value
13*
X!
*
X2#
# 13*
X!
*
X2#
# Aln
X!
*
X2#]
Specify the number of active lines.
Increment active lines value
13*
X!
+# 13*
X!
+# Aln
X!
*
X2#]
Increase the number of active lines value.
Decrement active lines value
13*
X!
-# 13*
X!
-# Aln
X!
*
X2#]
Decrease the number of active lines value.
View the active lines value
13*
X!
# 13*
X!
#
X2#]
Show the number of active lines.
N
X!
= Input number 1 – 6
X@
= Output number 1 = Program 2 = Preview 3 = PIP window 4 = PIP image
X2)
= Pixel sampling phase 000 – 031
X2!
= Total pixels Range depends on the input format.
X2@
= Active pixels Range depends on the input format.
X2#
= Active lines Range depends on the input format.
