SIS
Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-6
X4$
= Frequency: nnn.nn (kHz [horizontal] or Hz [vertical])
X4%
= Lockout mode:
0 = Unlocked
1 = Program lock — Lock Program buttons
2 = Switch free lock — Lock Picture Adjustments,
menu controls, and effect selection
3 = Volume free lock — Lock all controls except Volume
4 = Complete
N
See “Using front panel security lockouts (executive
modes)”, in chapter 3, “Operation”, for definitions
of these lockout modes.
X4^
= Firmware version
X4&
= Degrees Celsius
X3&
= PIP audio setting 1 = follow main window
2 = follow PIP window
X3*
= Border color:
0 = None 5 = Magenta
1 = Red 6 = Cyan
2 = Green 7 = Yellow
3 = Blue 8 = Black
4 = White
X3(
= Scan converter board output type:
0 = Composite/S-video
1 = YUV
2 = RGsB
X4)
= Scan converter board output standard:
0 = NTSC 1 = PAL
X4!
= Horizontal and flicker filter value (0 thru 3)
X4@
= Encoder filter level 0 to 3
X4#
= Detected input signal standard (0 through 4)
0 = none 3 = NTSC 4.43
1 = NTSC 3.58 4 = SECAM
2 = PAL
N
Dash (–) = not applicable (occurs when the input is
set for RGB or progressive YUV).
Switcher-Initiated Messages
When a local event such as power-up or a front panel operation occurs, the
switcher responds by sending a message to the host. The switcher-initiated
messages are listed on the following pages. The messages are underlined.
The switcher does not expect a response from the host, but the host program may
request a new status.
Power-up
(c) Copyright 2009, Extron Electronics, ISS 506 Series, Vx.xx, 60-742-nn]
The copyright message is initiated by the switcher when it is first powered on.
Vx.xx is the firmware version number.
Input selection
Out
X@
•In
X!
•All]
A front panel video and audio switching operation has occurred.
X@
is the output
number and
X!
is the input number.
Effect selection
Dissolve
Eff1*
X#
*nnn*1*n]
The operator has pressed the Effect Dissolve button on the front panel. Eff1
indicates “dissolve”. The second “1” indicates that this effect is selected.
X#
is the
dissolve duration. “nnn” and “n” have no meaning in this response.
Wipe
Eff2*
X#
*
X%
*1*n]
The operator has pressed the Effect Wipe button on the front panel. Eff2 indicates
“wipe”. The second “1” indicates that this effect is selected.
X#
is the wipe
duration.
X%
is the wipe subeffect. “n” have no meaning in this response.
