Cisco WAN Manager User’s Guide
Version 10.5, Part Number 78-12945-01 Rev. D0, August 2003
Chapter 2 Starting and Stopping Cisco WAN Manager
CWM Main Menu
Step 7 From the main menu, enter x to exit the CWM application.
Stopping CWM and Powering Off the CWM Workstation
This section describes the proper method of stopping the CWM application to power down the
workstation.
Step 1 In the CWM terminal window, switch to user root, and enter the following to halt the workstation:
# sync; sync; halt
Instead of the halt command, you can use the shutdown command to broadcast a shutdown message to
all logged-in users. Enter one of the following:
• # sync; sync; shutdown -i 0 -g 0 (firmware)
• # sync; sync; shutdown -i 5 -g 0 (power off)
• # sync; sync; shutdown -i 6 -g 0 (reboot)
Note If you issue a shutdown command, the following step is unnecessary.
Step 2 At the OK prompt, enter the following to power down the workstation:
OK power-off
CWM Main Menu
Upon launching CWM, the Main Menu is displayed, enabling you to initiate and terminate the CWM
core processes and to access the CWM Desktop window. You can also use the main menu to get the name
of the current database.
To launch Cisco WAN Manager and display the main menu, open a C-shell window on the workstation
where CWM has been installed, and complete the following steps:
Step 1 Log in as user svplus at the CWM workstation.
Step 2 Start CWM:
host% CWM
The CWM Main Menu is displayed as shown in Figure 2-1. To select any of the menu options, specify
the number and press Return.
Step 3 From the CWM Main Menu, start the CWM Core process. Specify 1 at the prompt then press Return
to initiate the Start Core option.
