Cisco WAN Manager User’s Guide
Version 10.5, Part Number 78-12945-01 Rev. D0, August 2003
Chapter 4 Connection Manager
Starting Connection Manager
Tool Bar
The Connection Manager tool bar contains icon buttons that access frequently used actions. The
following icons are available:
• Delete Template
• Edit Filter
• Help
Button Panel
The Connection Manager button panel contains the following navigational buttons:
• Apply—Allows you to apply selected filters to the list of connections.
• Refresh—Allows you to refresh the list of connections from the Connection Manager server, but not
apply any new filters to the connections.
• Modify—Allows you to modify a connection’s parameters.
• Delete—Allows you to delete connections.
Start Node Tree
The Connection Manager Start Node Tree shows the network equipment that is being managed by CWM.
You can select any node from the hierarchy to be the current start node. The label on the top of this pane
shows the current selected node.
Filter Settings Tree
The Connection Manager Filter Settings Tree displays the filter categories and values currently selected.
Click the Apply button to review the selected connection types.
List of Connections
The Connection Manager List of Connections lists a subset of connections managed by CWM based on
the selected start node and filter values.
Status Bar
The Connection Manager Status Bar displays any errors or informational messages as you attempt to
perform various actions.
Alarms and Events
After selecting a node from the Start Node Tree, or any slot, line, or port under a node in the tree, and
then selecting the Apply button, the Connection Manager will update alarms and events on selected
connections under the following circumstances:
