3-17
Cisco WAN Manager User’s Guide
Version 10.5, Part Number 78-12945-01 Rev. D0, August 2003
Chapter 3 Network Topology
Using the Network Topology Menus
Statistics Collection Manager
The Statistic Collection Manager option launches the Statistic Collection Manager (SCM) application.
The SCM provides a forms-based interface to establish and modify statistic collection policies for the
network.
Security Manager
The Security Manager option launches the Security Manager application. The Security Manager
provides controlled access to multiple users of CWM based on the unique user ID and password.
Summary Report
The Summary Report option launches the Summary Report application. CWM provides node
utilization reports not based on Wingz through the Summary Report application.
Wingz Report
The Wingz Report option launches the Wingz Report application. CWM Statistics Reports are
generated through a graphical reporting package based on the Informix Wingz Report application.
Cisco View
The CiscoView option brings up a CiscoView window that allows you to select a device in which to view
Telnet, CCO, Cisco Support, Preferences, About, and Help information.
WAN CiscoView is a JAVA-based device management software GUI application that allows you to:
• Display a graphical representation of the network device
• Display configuration and performance information
• Perform minor configuration tasks
• Perform minor troubleshooting tasks
WAN CiscoView supports card, line, and port configuration on the MGX 8220, 8230, 8250, Release 1
and 2 of the MGX 8850, IGX 8400 series, BPX 8600 series, and BPX SES PNNI Controller.
Please see your CiscoView documentation for more details about this feature.
Tools Menu
The Tools menu provides operations or applications that are launched from the main window of the
Network Topology, but are external to the Network Topology application.
Config Save and Restore
The Config Save and Restore option launches an application with In-Progress, Config Save, and Config
Restore tabbed windows which allow you to view and change criteria for the selected node in the current
submap.
