4-21
Cisco WAN Manager User’s Guide
Version 10.5, Part Number 78-12945-01 Rev. D0, August 2003
Chapter 4 Connection Manager
PVC Connections Supported by Release 10 of CWM
Table 4-9 PVC Connections Types
Connection CWM Service
Local Endpoint
Card Type
Remote
Endpoint Card
Type Comments or Restrictions
FR-FR none FR FR Choice of FR port types;
choice of ForeSight features;
no QOS support
FR-FR none
FRQOS FR,
FRQOS
Choice of FR port types;
ForeSight enabled for QOS types ubr and abr;
Following QOS specified by ‘ChanServType’ attribute
on FRSM-VHS SM:
hi_priority, ubr, nrt-vbr, rt-vbr, abr
ATM-FR
nrt-vbr3,abr.fs ATM FR
Choice of FR port types;
no QOS support on FR endpoint;
abr.fs not supported with ATM PXM service module
ATM-FR
cbr1,
ubr(1,2),
nrt-vbr(2,3),
abr.fs
ubr(1,2)
ATM FRQOS
Choice of FR port types;
QOS supported on FR endpoint
ATM-FR
rt-vbr(2,3) ATM FRQOS
Choice of FR port types;
QOS supported on FR endpoint;
ForeSight for abr.fs only;
abr.fs not supported with ATM PXM service module
ATM-FR
nrt-vbr3 RPMB FR
Choice of FR port types;
no QOS support on FR endpoint
ATM-FR
nrt-vbr3 RPMB FRQOS
Choice of FR port types;
QOS supported on FR endpoint
ATM-ATM
cbr1,
nrt-vbr(1,2,3),
ubr(1,2),
abr.1,abr.fs
ATM ATM
No Foresight (except for abr.fs);
rt-vbr available only if both network and service
modules support ‘rt’ feature;
no ForeSight supported with cbr and with PXM cards
ATM-ATM
rt-vbr(1,2,3) ATM ATM
No Foresight;
real time feature should be supported by the network
and the ATM service modules
ATM-ATM
atfst. atfxt, atft-
txt
ATM (BXM) ATM (BXM)
ForeSight supported;
both endpoints should be BXM/BXM-E cards
ATM-ATM
cbr1,
nrt-vbr(1,2,3),
ubr(1,2),
abr.1,abr.fs
ATM-Multicast ATM-Multicast
No Foresight (except for abr.fs);
multicast connection;
local and remote port combinations: root-root,
root-leaf
ATM-ATM
nrt-vbr3
abr1
ubr1
ATM/RPM ATM/RPM
No Foresight;
one or both endpoint router service modules
VISM-ATM
cbr1
vbr1_rt
vbr1_nrt
VISM ATM
