LOAD/SAVE Menu
3 Ć248
AWG2021 User Manual
(1) Internal memory file list This is a list of the files currently loaded into internal memory.
The list shows the file names, the file types, file sizes (in
bytes), the date and time the file was created, and a comment.
The space remaining in internal memory, into which files can
be loaded, is displayed in the upper rightĆhand corner of the
list.
For the LOAD menu, when a file is loaded into internal
memory from mass memory or from another instrument
through the GPIB interface, that file is added to this list.
For the SAVE menu, you can select files to save from this list
to mass memory.
(2) Mass memory file list This list is displayed when mass memory has been selected for
Device. It contains all files that have been saved to mass
memory. The file data is the same as in (1), above.
For the LOAD menu, you can select files to load from this list
to the AWG2021 internal memory.
For the SAVE menu, when a file is saved from internal memory
of the instrument to mass memory, the saved file is added to
this list.
(3) GPIB file list This list is displayed when GPIB has been selected for Device.
It shows all other instruments connected to this instrument
through the GPIB interface. Waveform data can be sent to the
internal memory of this instrument from the instruments shown
in this list. When waveform files are loaded in this manner, a
name appears in the Loaded as" column.
