Appendix C: Performance Verification
AWG2021 User Manual
CĆ7
Table CĆ1: Test Equipment (Cont.)
Item PurposeExampleMinimum Requirements
Digital multimeter DC volts range: 0.05ĂV to 5ĂV
Accuracy: ±0.1%
Fluke 8842A Used throughout the checks
to measure voltage.
Function generator Output voltage: -5ĂV to 5ĂV Tektronix FG 5010 ProgramĆ
mable Function Generator
*
Used to input the trigger
signal.
Power supply (Option 03) Output voltage: -2ĂV Tektronix PS 5010 ProgramĆ
mable Power Supply
*
Used to check ECL digital
data output.
Performance Check/AdjustĆ
ment disk
Must use example listed Tektronix Part 063Ć2171ĆXX Used throughout the checks
to provide waveform files.
* Requires a TM 5000 Series Power Module Mainframe.
Table C-2 lists the waveform files on the Performance Check/Adjustment disk
(063-2171-XX) that are used in these performance tests, the AWG2021
front-panel settings that each file sets up, and the performance test that uses each
file.
NOTE. The files on the Performance Check/Adjustment disk are locked (the files
names are displayed with *), so the data in these files cannot be changed unless
the lock is opened. The file data includes not only waveform data, but also
output parameters.
When you select a file with the Waveform Sequence item, the AWG2021 output
parameters change to those specified in the file, and the waveform output
reflects waveform data in the file. After selecting a file, do not change an output
parameter with the SETUP menu unless a procedure instructs you to do so.
During the procedures, if you are unsure that the AWG2021 settings still match
the file’s settings, select the waveform again using the Waveform Sequence item
on the SETUP menu.
HF_LF.WFM file on the Performance Check/Adjustment disk is used to adjust
the AWG2021 externally. On adjustment, see the AWG2021 Service Manual.
Performance Check/
Adjustment Files
