Appendix B: Performance Characteristics
BĆ6
AWG2021 User Manual
Warranted Characteristics
This section will describe the warranted characteristics of the AWG2021. These
can be divided into two main categories: electrical characteristics and environ-
mental characteristics.
The electrical characteristics are valid under the following conditions:
1. The instrument must have been calibrated at an ambient temperature between
+20_ C to +30_ C.
2. The instrument must be in an environment whose limits are described in
Environmental Characteristics.
3. All tolerance limits apply after a 20 minute warm up and an execution of the
self calibration.
4. The instrument is operating at an ambient temperature between +10_ C to
+40_ C, unless otherwise noted.
Items marked with ** are tested in the Performance Verification (Appendix C)
Table BĆ3: Electrical Characteristics
Characteristics Description
Clock Generator
** Accuracy
** +15_ C to +30_ C
0.005%
+10_ C to +40_ C
0.01%
Skew between CH1 and CH2 When Option 02 (second channel) installed within 4 ns
Filter
Cutoff frequency
-3 dB point
1 MHz within 20%
5 MHz within 20%
20 MHz within 20%
50 MHz within 20%
Main Output
** Amplitude
DC Accuracy
0.05 V 0.5 V ±(0.5% of Amplitude+5mV)
No Offset, at 1 MHz clock
** 0.501 V 5V ±(1% of Amplitude + 25 mV)
No Offset, at 1 MHz clock
Performance Conditions
