DES-7200 Configuration Guide Chapter 1 VRRP Configuration
1-13
DES-7200# show vrrp brief
Interface Grp Pri Time Own Pre State Master addr Group addr
GigabitEthernet0FastEthernet0/0 1 100 3- - P Backup 192.168.201.213
192.168.201.1
GigabitEthernet0FastEthernet0/0 2 120 - - P Master 192.168.201.217
192.168.201.2
The information displayed above includes the Ethernet interface name, VRRP group
number, priority, timeout period for backup turning into master, same as the interface
IP address or not, preemption mode, master device IP address, and VRRP group IP
address.
3. show vrrp interface command
DES-7200# show vrrp interface FastEthernet 0/1
GigabitEthernetFastEthernet 0/1 - Group 1
State is Backup
Virtual IP address is 192.168.201.1 configured
Virtual MAC address is 0000.5e00.0101
Advertisement interval is 3 sec
Preemption is enabled
min delay is 0 sec
Priority is 100
Master Router is 192.168.201.213 , pritority is 120
Master Advertisement interval is 3 sec
Master Down interval is 9 sec
FastEthernet 0/1 - Group 2
State is Master
Virtual IP address is 192.168.201.2 configured
Virtual MAC address is 0000.5e00.0102
Advertisement interval is 3 sec
Preemption is enabled
min delay is 0 sec
Priority is 120
Master Router is 192.168.201.217 (local), priority is 120
Master Advertisement interval is 3 sec
Master Down interval is 9 sec
DES-7200#
The displayed messages above include the specified Ethernet name, VRRP backup
group number configured on the interface, status, priority, preemption mode, VRRP
advertisement interval, virtual IP address, virtual MAC address, Master router IP
address, Master router priority, Master router advertisement interval, Master router
failure judgment interval, current interface monitored by the VRRP backup group and
corresponding priority change scale.
1.4.2 debug vrrp
Our produce has the following debug vrrp commands to provide the VRRP status
debugging information of the local router.
