DES-7200 Configuration Guide Chapter 3 BFD Configuration
3-32
Field Description
Hello (hits) The minimum interval of receiving the
Hello packet after the session
negotiation.
Rx Count The count of BFD packets received on
the local end.
Rx Interval (ms) min/max/avg The minimum/maximum/average
interval of receiving the session on the
local end.
Tx Count The count of BFD packets sent on the
local end.
Tx Interval (ms) min/max/avg The minimum/maximum/average
interval of sending the session on the
local end.
Registered protocols Type of protocol registered to the
session
Uptime Time of keeping the session UP.
Last packet Last BFD packet received on the local
end.
Table-1 Filed Description of the Session Displaying
2) View the BFD session of RouterB
DES-7200# show bfd neighbors details
OurAddr NeighAddr LD/RD RH Holdown (mult)
State Int
192.168.3.2 192.168.3.1 2/1 1 532 (5 ) Up
Ge2/1
Local Diag: 0, Demand mode: 0, Poll bit: 0
MinTxInt: 50000, MinRxInt: 50000, Multiplier: 3
Received MinRxInt: 200000, Received Multiplier: 5
Holdown (hits): 600(22), Hello (hits): 200(84453)
Rx Count: 49824, Rx Interval (ms) min/max/avg: 209/440/332
Tx Count: 84488, Tx Interval (ms) min/max/avg: 153/249/197
Registered protocols: RIP
Uptime: 02:18:49
Last packet: Version: 1 - Diagnostic: 0
I Hear You bit: 1 - Demand bit: 0
Poll bit: 0 - Final bit: 0
Multiplier: 5 - Length: 24
My Discr.: 1 - Your Discr.: 2
Min tx interval: 200000 - Min rx interval: 200000
