DES-7200 Configuration Guide Chapter 6 BGP
Configuration
6-8
Command Function
{address |
peer-group-name}update-source
interface
interfaces to establish the BGP
session with specified BGP peer
(group).
DES-7200(config-router)# neighbor
{address | peer-group-name}
ebgp-multihop [ttl]
(Optional) Allow to establish the BGP
session among non-direct-connected
EBGP peer (group).
The range of TTL is 1 to 255, the
EBGP is 1 hop by default, and the
IBGP is 255 hops by default.
DES-7200(config-router)#
neighbor{address | peer-group-name}
password string
(Optional) Enable the TCP MD5
authentication when the connection
is established among specified BGP
peer (group), and configure the
password.
DES-7200(config-router)# neighbor
{address | peer-group-name} times
keepalive holdtime
(Optional) Configure the Keepalive
and Holdtime value to establish the
connection with the specified BGP
peer (group).
The range of the keepalive is 0 to
65535 seconds, 60 seconds by
default.
The range of the holdtime is 0 to
65535 seconds, 180 seconds by
default.
DES-7200(config-router)# neighbor
{address | peer-group-name}
advertisemet-interval seconds
(Optional) Configure the minimal time
interval to send the routing update
message to the specified BGP peer
(group).
The range of advertisement-interval
is 1 to 600 seconds, the IBGP peer is
15 seconds by default, and the EBGP
peer is 30 seconds by default.
DES-7200(config-router)# neighbor
{address | peer-group-name}
default-originate [route-map
map-tag]
(Optional) Configure to send the
default route to the specified BGP
peer (group).
DES-7200(config-router)# neighbor
{address | peer-group-name}
next-hop-self
(Optional) Configure to set the next
route information as this BGP
speaker when the route is distributed
to the specified BGP peer (group).
